Evi Air to Water Heat Pump, Heating & Cooling & Hot Water, 9kw 15kw 18kw 24kw Capacity

Quantity:
  • MG-05(FT)
  • 8415812000
EVI air to water Heat Pump,Heating & Cooling & Hot Water,9kW 15kW 18kW 24kW Capacity
Model MG-03(FT)/220 MG-05(FT)/220 MG-03(FT)/380 MG-05(FT)/380 MG-07(FT)/380
Heating capacity

20ºC
kW 10.5 18.5 11 20 28
Heating input power kW 2.59 4.48 2.70 4.85 6.76
Rated current A 12.4 21.4 5.4 9.7 13.5
COP 4.06 4.13 4.07 4.12 4.14
Hot water capacity L/H 226 398 236 430 602
Heating capacity

7ºC
kW 8.4 14.8 8.8 16 22.4
Heating input power kW 2.47 4.31 2.57 4.65 6.49
COP 3.40 3.43 3.42 3.44 3.45
Hot water capacity L/H 181 318 189 344 482
Heating capacity

-10ºC
kW 5.9 10.4 6.2 11.2 15.7
Heating input power kW 2.30 4.03 2.39 4.32 6.03
COP 2.56 2.57 2.58 2.59 2.60
Hot water capacity L/H 126 223 132 241 337
Heating capacity

-20ºC
kW 4.4 7.8 4.6 8.4 11.8
Heating input power kW 2.21 3.85 2.30 4.12 5.74
COP 2.00 2.02 2.01 2.04 2.05
Hot water capacity L/H 95 167 99 181 253
Power supply 220~240V/50Hz/1ph 380~415V/50Hz/3ph
Rated/Max outlet water ºC 55/60
Refrigerant R407C
Copeland Compressor ZW34KSE ZW52KSE ZW34KSE ZW61KSE ZW79KSE
Condenser High efficiency shell and tube heat exchanger
Economy unit Plate heat exchanger
Throttle unit Thermal expansion valve
Connect pipe size of gas mm φ12.7/φ19 φ12.7/φ19 φ12.7/φ19 φ12.7/φ19 φ12.7/φ19
Power supply line size 2.5mm2 2.5mm2 4mm2 4mm2 5mm2
Indoor unit quantity PCS 1 1 1 1 1
Outdoor unit quantity PCS 1 1 1 1 1
Water flow m3/H 2.3 4.0 2.4 4.3 6.0
Pipe size DN25 DN25 DN25 DN25 DN25
Noise dB(A) ≤55 ≤55 ≤60 ≤60 ≤60
Outdoor unit N./G. weight
kg
85/90 130/135 85/90 130/135 140/145
Indoor unit N./G. weight 35/40 45/50 35/40 45/50 45/50
Indoor unit dimention mm L*W* H 660*385*900 660*385*900 660*385*900 660*385*900 680*400*900
Outdoor unit dimension mm 830*490*1160 1095*420*1420 830*490*1160 1095*420*1420 1237*480*1410

Evi Air to Water Heat Pump, Heating & Cooling & Hot Water, 9kw 15kw 18kw 24kw Capacity

Evi Air to Water Heat Pump, Heating & Cooling & Hot Water, 9kw 15kw 18kw 24kw Capacity
Evi Air to Water Heat Pump, Heating & Cooling & Hot Water, 9kw 15kw 18kw 24kw Capacity

Q: Are you heat pump supplier of trading company or manufacturer ?


A: We are R&D and manufacturer factory. With 9500 sq meters modern factory in Guangzhou City with OEM service provided, MOQ> 5 Units.

Q: How long is your EVI & Split Heat Pump delivery time?


A: Generally it is 1-5 working days if the goods are in stock. or it is 15-25 working days if the goods are not in stock, it is according to quantity.

Q: Do you also provide other kind of heat pump?


A: ASHP of EVI(9KW-132KW) | DC INVERTER (4KW-30KW) | EVI INVERTER(20KW/22KW) | SWIM POOL(5KW-150KW),HIGH TEMPPERATURE HEAT PUMP,WATER TO WATER HEAT PUMP,GROUND SOURCE HEAT PUMP,HOUSE USE HEAT PUMP.AIR SOURCE HEAT PUMP(HOT WATER/HEATNG OR WITH COOLING TOGETHER)

Q: What is your terms of payment for heat pump ?


A: Payment<= 8000USD, 100% in advance. Payment>= 8000USD, 30% T/T in advance ,balance before shippment.
L/C Payment available only with 1 millon+ USD dealing amount.
