| Quantity: | |
|---|---|
1.Equiped with famous brand copeland compressor
2.The the heatig temperature could be set,and the outlet temperature would be the temperature you set.
3.With intelligient touch screen,it can adjust the water temperature and set the heating time.
4.With full protection functions including water flow, high/low pressure, phase order, over-current etc.
5.The cop is more than 4.0,high efficiency;
6.Meet a large consumption,stable and reliable hot water output and performance,high energy efficiency ratio,constant water tank temperature to ensure comfortable use.
7.The unit runs more stable, reliable without EHV(exceed high voltage)
Debase efficiently the attenuation of the heat exchange rate,assure hot water capacity.Adopting high efficient tube heat exchanger, waster rate is greatly reduced, long-term and stable operation.
8.Water tank volume seleted freely, more practical
9.Water and electricity system is completely separated, assure using safely
10.Intelligent control
With automatic filling water,water level control,defrost, power-fail memory,charge adjustment system,with booking timed heating,LCD display remote control and clock.
| Model No. | Unit | MG-030KFXRS | MG-050KFXRS | MG-080KFXRS | MG-100KFXRS | MG-120KFXRS | MG-200KFXRS | MG-250KFXRS | ||||
| Heating Capacity | KW | 10.8 | 18 | 28.8 | 38 | 43.2 | 72 | 86.4 | ||||
| Power Input | KW | 2.7 | 4.5 | 7.2 | 9.6 | 10.8 | 18 | 21.6 | ||||
| Largest Current | A | 5.9 | 5.9 | 9 | 11.2 | 17.6 | 36.1 | 41.4 | ||||
| Rated Water Temp. | ºC | 55 | 55 | 55 | 55 | 55 | 55 | 55 | ||||
| Highest Water Temp. | ºC | 60 | 60 | 60 | 60 | 60 | 60 | 60 | ||||
| Power Supply | 220V/1P/50Hz | 380V/3P/50Hz | ||||||||||
| Anti-electric Shock Type | ||||||||||||
| Compressor | Scroll | |||||||||||
| Compressor brand | Copeland | |||||||||||
| Quantity of Compressor | 1 | 1 | 2 | 2 | 4 | 4 | ||||||
| Fan Direction | Discharge | Vertical | ||||||||||
| Quantity of Fan | 1 | 1 | 2 | 2 | 3 | 3 | ||||||
| Refrigerant | R417A | |||||||||||
| Ambient temp. | ºC | -10-45 | -10-45 | -10-45 | -10-45 | -10-45 | -10-45 | -10-45 | ||||
| Hot Water Supply | L/H | 267 | 400 | 620 | 817 | 928 | 1548 | 1856 | ||||
| Pipe Size | Inch | 1″ | 1″ | 1 1/4″ | 1 1/4″ | 2 1/2″ | 2 1/2″ | |||||
| Circulation of Water Capacity | M3/h | 3 | 5 | 8 | 10 | 12 | 20 | 24 | ||||
| Pressure from Tap Water | kPa | 46 | 46 | 46 | 46 | 46 | 46 | 46 | ||||
| Noise | dBA | <=54 | <=56 | <=60 | <=60 | <=60 | <=62 | <=62 | ||||
| Mainframe Weight | kg | 100 | 180 | 340 | 360 | 380 | 680 | 760 | ||||
| Dimension(mm) | Length | 810 | 1110 | 1500 | 1500 | 1430 | 2170 | 2170 | ||||
| Width | 691 | 490 | 800 | 800 | 780 | 1065 | 1065 | |||||
| Height | 870 | 1260 | 1600 | 1600 | 1376 | 1890 | 1890 | |||||
| Running conditions: Ambient temperature DB(dry bulb) 20 ºC, WB(wet bulb)15ºC, Inlet water temp:15ºC, Outlet water temp:55ºC. | ||||||||||||
