| Quantity: | |
|---|---|
1) With titanium(outer PVC,inner titanium)heat exchanger,its max.pool temp.is 40°C
2) Other titanium( outer steel,inner titanium) heat exchanger is on your option,its max. pool temp. is 60°C.
3) Suitable for -10°C~+45°C ambient temperature.
4) Safety: Eliminated the problems of traditional normal water generator.
5) Reliable: Service life can reach up to 15 years. Low maintenance cost.
6) Modular design: We can add on more units according to user's requirement.
7) All weather operation: Running without being effected by weather, even snow or rain.
8) Environment protection: No pollution and waste needs to discharge in entire working cycle.
9) Economy: The running costs of a heat pump can be less than those of a traditional gas boiler heating system.
10)Simple installation: It can be placed on the roof top, balcony, yard, or basement, and it doesn't need special room.
11) We usually adjust outlet water temperature at the range of 28°C~30°C(normal) for swimming pool use, also according to user's requirement.
| Model | MG-13 | MG-18 | MG-27 | |
| Power supply | V/Ph/Hz | 220/1/50 | 220/1/50 | 220/1/50 |
| Heating capacity | kW | 4.8 | 7.1 | 11 |
| BTU | 16378 | 24225 | 37532 | |
| Power input by heating | kW | 1.1 | 1.5 | 2.3 |
| Cooling capacity | kW | 3.7 | 5.3 | 7.5 |
| BTU | 12624 | 18084 | 25590 | |
| Power input by cooling | kW | 1.4 | 1.9 | 2.8 |
| Refrigerant | R410A | R410A | R410A | |
| Required hot water flow rate | m3/h | 2 | 3 | 4.5 |
| Water connection diameter | mm | 50 | 50 | 50 |
| Noise | dB(A) | ≤48 | ≤48 | ≤48 |
| Max. current | A | 9.5 | 13 | 7.2 |
| Compressor | Type | Rotary | Rotary | Rotary |
| Fan | Qty | 1 | 1 | 1 |
| Rated outlet water temp. | °C | 28 | 28 | 28 |
| Max. water temp. | °C | 45 | 45 | 45 |
| Operation temp. range | °C | -55 | -55 | -55 |
| Net weight | kg | 58 | 67 | 84 |
| Net size(L/W/H) | mm | 1005×305×620 | 1005×305×620 | 1115×425×715 |
| Heating by Ambient temp.(DB/WB):20°C /15°C and Water temp.(in /out): 15°C/28°C; | ||||
| Cooling by Ambient temp.(DB/WB):35°C /24°C and Water temp.in 28°C; | ||||
| Above information just for your reference, Please subject to the nameplate on the unit | ||||
| Refrigerant is optional | ||||
1) With titanium(outer PVC,inner titanium)heat exchanger,its max.pool temp.is 40°C
2) Other titanium( outer steel,inner titanium) heat exchanger is on your option,its max. pool temp. is 60°C.
3) Suitable for -10°C~+45°C ambient temperature.
4) Safety: Eliminated the problems of traditional normal water generator.
5) Reliable: Service life can reach up to 15 years. Low maintenance cost.
6) Modular design: We can add on more units according to user's requirement.
7) All weather operation: Running without being effected by weather, even snow or rain.
8) Environment protection: No pollution and waste needs to discharge in entire working cycle.
9) Economy: The running costs of a heat pump can be less than those of a traditional gas boiler heating system.
10)Simple installation: It can be placed on the roof top, balcony, yard, or basement, and it doesn't need special room.
11) We usually adjust outlet water temperature at the range of 28°C~30°C(normal) for swimming pool use, also according to user's requirement.
| Model | MG-13 | MG-18 | MG-27 | |
| Power supply | V/Ph/Hz | 220/1/50 | 220/1/50 | 220/1/50 |
| Heating capacity | kW | 4.8 | 7.1 | 11 |
| BTU | 16378 | 24225 | 37532 | |
| Power input by heating | kW | 1.1 | 1.5 | 2.3 |
| Cooling capacity | kW | 3.7 | 5.3 | 7.5 |
| BTU | 12624 | 18084 | 25590 | |
| Power input by cooling | kW | 1.4 | 1.9 | 2.8 |
| Refrigerant | R410A | R410A | R410A | |
| Required hot water flow rate | m3/h | 2 | 3 | 4.5 |
| Water connection diameter | mm | 50 | 50 | 50 |
| Noise | dB(A) | ≤48 | ≤48 | ≤48 |
| Max. current | A | 9.5 | 13 | 7.2 |
| Compressor | Type | Rotary | Rotary | Rotary |
| Fan | Qty | 1 | 1 | 1 |
| Rated outlet water temp. | °C | 28 | 28 | 28 |
| Max. water temp. | °C | 45 | 45 | 45 |
| Operation temp. range | °C | -55 | -55 | -55 |
| Net weight | kg | 58 | 67 | 84 |
| Net size(L/W/H) | mm | 1005×305×620 | 1005×305×620 | 1115×425×715 |
| Heating by Ambient temp.(DB/WB):20°C /15°C and Water temp.(in /out): 15°C/28°C; | ||||
| Cooling by Ambient temp.(DB/WB):35°C /24°C and Water temp.in 28°C; | ||||
| Above information just for your reference, Please subject to the nameplate on the unit | ||||
| Refrigerant is optional | ||||
