CE, TUV Swimming SPA pool heat pump water heater
| Model | MGY-010IC | MGY-015IC | MGY-020IC | MGY-025IC | |
| Heating capicity(A24/W28) | Kw | 3.8 | 5.6 | 8.5 | 10.5 |
| Input power | Kw | 0.69 | 1.02 | 1.55 | 1.91 |
| COP | 5.5 | 5.5 | 5.5 | 5.5 | |
| Current | A | 3.3 | 4.9 | 7.4 | 9.1 |
| Heating capicity(A15/W28) | Kw | 3.23 | 4.8 | 7.2 | 8.9 |
| Input power | Kw | 0.71 | 1.04 | 1.58 | 1.96 |
| COP | 4.6 | 4.6 | 4.6 | 4.6 | |
| Current | A | 3.4 | 5.0 | 7.6 | 9.4 |
| Voltage | V/Hz | 220~240V-50Hz/1Ph | |||
| Rated/Max water temp | 28~40°C | ||||
| Hot water produce | L/H | 251 | 370 | 562 | 694 |
| Water flow | m3/H | 1.3 | 1.9 | 2.9 | 3.6 |
| Refrigeration | R410A/R417A | ||||
| Compressor | Panasonic/Sanyo/Mitsubishi Rotary | ||||
| Condenser | Titanium heat exchanger | ||||
| Evaporator | Blue Finned heat exchanger | ||||
| Fan motor | 30W*1 | 30W*1 | 45W*1 | 50W*1 | |
| Throttle unit | Danfoss EEV | ||||
| Controller | LCD wire controller | ||||
| Ambient temperature | （-10℃ -- 45℃） | ||||
| Water pipe size | φ50 | φ50 | φ50 | φ50 | |
| Noise | dB(A) | ≤45 | ≤48 | ≤50 | ≤52 |
| Dimension | mm | 970*300*550 | 970*300*550 | 1006*350*618 | 1006*350*618 |
| Weight | Kg | 45 | 50 | 58 | 65 |
