| Model | MGSDC-030IC | MGSDC-050IC | MGSDC-060IC | ||
| Rated heating capicity | Air (DB/WB): 7ºC /6ºC Water (in/out): 30ºC/35ºC | Kw | 9 | 15 | 18 |
| Heating capicity min-max | Kw | 3.2-11.5 | 5.4-18.5 | 5.4-21.0 | |
| Rated input Power | Kw | 2.07 | 3.46 | 4.21 | |
| Input Power min-max | 0.55-4.0 | 0.92-6.2 | 0.92-7.0 | ||
| COP | 4.35 | 4.33 | 4.28 | ||
| COP min-max | 3.2-5.8 | 3.25-5.86 | 3.25-5.86 | ||
| Rated Current | A | 9.4 | 15.74/5.25 | 19.11/6.39 | |
| Rated cooling capicity | Air (DB/WB): 35ºC /24ºC Water (in/out): 12ºC/7ºC | Kw | 7.5 | 12 | 14 |
| Cooling capicity min-max | Kw | 2.8-9.0 | 4.6-14.0 | 4.6-15.8 | |
| Rated input Power | Kw | 2.38 | 3.80 | 4.46 | |
| Input Power min/max | 0.7-4.1 | 1.15-6.4 | 1.15-7.15 | ||
| EER | 3.15 | 3.16 | 3.14 | ||
| EER min/max | 2.63-4.0 | 2.62-4.0 | 2.60-4.0 | ||
| Rated Current | A | 10.8 | 17.2/5.77 | 20.26/6.77 | |
| Voltage | V/Hz | 220~240V-50Hz/1Ph | 220~240V-50Hz/1Ph or 380~415V-50Hz/3Ph | ||
| Heating output water temperature | 20~60°C | ||||
| Cooling output water temperature | 5~31°C | ||||
| Outdoor air flow | m3/H | 2800 | 5600 | 5600 | |
| Water flow | m3/H | 1.9 | 3.2 | 3.9 | |
| Design pressure | Mpa | 4.2 | 4.2 | 4.2 | |
| Refrigeration | R410A | ||||
| Compressor Brand | Panasonic Inverter Rotary | ||||
| Compressor quantity | 1 | 1 | 1 | ||
| Condenser | Stainless steel plate HE | ||||
| Evaporator | Finned heat exchanger | ||||
| Throttle unit | Electronic expansion valve | ||||
| Controller | LCD wire controller | ||||
| Built-in electric heater (optional) | 3kw | 3kw | 3kw | ||
| Built-in circulation pump (optional) | Wilo RS-25/8 | Wilo RS-25/8 | Wilo RS-25/8 | ||
| Ambient temperature | (-25ºC -- 45ºC) | ||||
| Pipe Size Liquid/Gas | 9.52-15.88 | 12.7-19.02 | 12.7-19.02 | ||
| Outdoor/Indoor Noise | dB(A) | ≤60/≤40 | ≤63/≤46 | ≤63/≤46 | |
| Outdoor unit dimension | mm | 920*340*820 | 1030*400*1330 | 1030*400*1330 | |
| Indoor unit dimension | mm | 485*350*690 | 485*350*690 | 485*350*690 | |
| Outdoor unit Weight | Kg | 60 | 105 | 105 | |
| Indoor unit Weight | Kg | 35 | 45 | 45 | |
| Heating testing condition : air temperature (DB/WB): 7ºC/6ºC, water temperature (inlet/outlet):30ºC/35ºC. | |||||
| Cooling testing condition : air temperature (DB/WB): 35ºC/24ºC, water temperature (inlet/outlet):12ºC/7ºC. | |||||
