You are here: Home » Products » Air to watet heat pump cooling +heating unit » ERP A+++ WIFI Air Source Heat Pump for Heating Cooling and Hot Water with DC Inverter Monoblock Heatpump

Product Detail

Share to:

ERP A+++ WIFI Air Source Heat Pump for Heating Cooling and Hot Water with DC Inverter Monoblock Heatpump

MGSDC-080IIC Model
Availability:
Quantity:
  • MGSDC-080IIC
  • Mango
  • 8418619098
  • Mango Energy
  • CE, ISO9001, CB, UL, RoHS, SASO, CSA
  • Plywood
  • China
  • 1175*400*1482mm
  • Villa, Hotel, Garage, Sauna, Apartment Household etc.
Product Description
Name
Monoblock  DC Inverter Air Source Heat Pump with WIFI Control
Function
Heating/Cooling/Hot Water
ERP
A+++
Material
Galvanized sheet metal
Package
Wooden


Parameter

Model
MGSDC-030IIC
MGSDC-050IIC
MGSDC-060IIC
MGSDC-080IIC
Power Supply
V/Hz/P
220-240V~/50Hz/1ph, 380-415V/50Hz/3ph
Refrigerant Type

R32
[Space Heating] Ambient Temp. (DB/WB): 7°C/6°C, Water Temp. (Inlet/Outlet): 30°C/35°C
Max Heating Capacity
kW
2.32-9.65
3.53-15.76
4.81-18.85
6.36-25.14
Power Input
kW
0.38-2.10
0.58-3.49
0.81-4.31
1.08-5.81
COP

6.06-4.59
6.01-4.51
5.89-4.37
5.87-4.33
[Space Heating] Ambient Temp. (DB/WB): 7°C/6°C, Water Temp. (Inlet/Outlet): 50°C/55°C
Max Heating Capacity
kW
1.81-7.83
2.38-10.86
2.82-14.12
3.41-17.69
Power Input
kW
0.43-3.05
0.58-4.31
0.64-5.34
0.89-7.04
COP

4.15-2.56
4.11-2.52
4.37-2.64
4.32-2.51
[Space Heating] Ambient Temp. (DB/WB): -10°C/-12°C, Water Temp. (IOutlet): 35°C
Max Heating Capacity
kW
1.32-6.8
1.95-12.38
2.17-14.55
2.74-16.74
Power Input
kW
0.38-2.44
0.56-4.22
0.63-5.0
0.80-5.98
COP

3.46-2.79
3.48-2.83
3.46-2.81
3.42-2.80
[Space Heating] Ambient Temp. (DB/WB): -10°C/-12°C, Water Temp. (Outlet): 55°C
Max Heating Capacity
kW
1.10-5.68
1.61-11.02
1.95-13.13
2.43-15.54
Power Input
kW
0.34-2.24
0.50-4.32
0.60-5.09
0.75-6.07
COP

3.22-2.53
3.21-2.55
3.27-2.58
3.24-2.56
[Space Heating] Ambient Temp. (DB/WB): -20°C/-21°C, Water Temp. (Outlet): 35°C
Max Heating Capacity
kW
1.32-5.7
1.95-11.05
2.17-13.15
2.74-15.32
Power Input
kW
0.43-2.29
0.64-4.49
0.71-5.32
0.91-6.13
COP

3.05-2.49
3.04-2.46
3.07-2.47
3.01-2.50
[Space Heating] Ambient Temp. (DB/WB): -20°C/-21°C, Water Temp. (Outlet): 55°C
Max Heating Capacity
kW
1.02-5.1
1.35-10.34
1.46-12.19
1.98-14.67
Power Input
kW
0.36-2.33
0.48-4.74
0.52-5.72
0.70-6.82
COP

2.80-2.19
2.84-2.18
2.79-2.13
2.83-2.15
[Space Cooling] Ambient Temp. (DB/WB): 35°C / 24, Water Temp. (Inlet/Outlet): 12°C/7°C.
Max Cooling Capacity
kW
1.43-7.80
2.06-11.40
2.63-14.50
3.31-20.52
Power Input
kW
0.32-2.92
0.46-4.3
0.59-5.53
0.76-7.86
COP

4.45-2.68
4.43-2.65
4.41-2.62
4.32-2.61
[Hot Water] Ambient Temp. (DB/WB): 20°C/15°C, Water Temp. from 15°C to 55°C.
Max Heating Capacity
kW
10.5
16
19.5
24.8
Power Input
kW
2.18
3.36
4.04
5.23
COP

4.82
4.76
4.83
4.74
General Info.
ErP Level (35°C)

A+++
ErP Level (55°C)

A++
Max. Power Input
kW
3.3+3/3.5+3
6+3/6.5+3
6+3/6.5+3
7.7+3/8.0+3
Max. Running Current
A
15+13.6/5.3x3+13.6
9.1+13.6/9.85x3+13.6
9.1+13.6/9.85x3+13.6
35+13.6/12.12x3+13.6
Compressor Brand

Panasonic
Fan Motor Type

DC Motor
Water Side Heat Exchanger

SUS 316 Brazed plate heat exchanger
Air Side Heat Exchanger

Finned Heat Exhanger
Display

Micro processor based digital wire controller with LCD display
Wi-Fi Function

Yes
Rated Water Flow
m³/h
≥1.6
≥2.1
≥2.7
≥3.4
Water Pressure Drop
kPa
30
38
38
45
Water Pipe Connection
inch
1"
1"
1"
1-1/4"
Sound Pressure Level at 1m
dB(A)
43~54
43~55
44~55
45~58
Operation Range
°C
-30~43
Max. Outlet Water Temp.
°C
55~60
Water Proof Class

IPX4
Electricity Shock Proof

I
Net Weight
kg
76
120
140
165
Net Dimensions (L×W×H)
mm
925X375X745
1050X400X1350
1050X400X1350
1175X400X1482
Package Dimensions (L×W×H)
mm
1010X435X890
1130X460X1460
1130X460X1460
1220X500X1570

DC Inverter heat pump Advantages:
1.R32 Refrigerant pipe connection for best system stability even in tough weather.

2.E-heater, diverter valve,water pump,and expansion tank can be included.

3.A+++ Energy Rating Level,with CE,TUV test report.

4.Low noise sound power level as low as 52dB(A)

5.Work down to -30 degree C



What we can get? --Mango Energy multi-function

Why choose us? --Your ideal home

Adopt RS485 intelligent care controller, connect WiFi and control it anytime, anywhere.


Top core component supply.

Drawing of heat pump floor heating


How do we install--So Easy!

Drawing of heat pump heating and cooling

Drawing of heat pump radiatior heating

Company profile

The formula has a long history.
FAQ

1:Are you a manufacturer?

Of course, Mango is professional heat pump manufacturer since 2019, with experienced and improved R&D, production, sales and service supplying.

2: Do you accept OEM & ODM?

Yes. We can produce standard products under clients' brand, modify the products to satisfy client's personalized requirements and work together with clients to design and produce a totally new products.


3: What support do you offer to clients?

We can provide product certification requirements for local markets; provide catalogs, technical manuals; co-exhibit with the clients in leading industry exhibitions; do promotion on the local market’s media by our news release resources.


4: Will you provide technical promotion support?

Sure, we can provide corresponding pictures and videos to you.


5: How is your price?
We have our own factory not the trading company. There is no middleman between clients and us. We give customers the most favorable price.

6: How long is your Heat Pump delivery time?
It is 3-7 working days if the goods are in stock. if the goods are not in stock, Generally 21-30 working days,it is according to quantity.
