House use/Commercial use floor heating heat pump
| Item no | MG-05DN | | |
| Power supply | 220/50Hz | Waterproof grade | IPX4 |
| Nominal heating capacity | 18kw | Rated water pressure | 0.6MPa |
| Rated power input | 4.4kw | Air conditioner cooling | 15kw |
| Rated current input | 21.0A | Air conditioner heating | 19.5kw |
| Power input | 5.4kw | AC min outlet water temp | 7ºC |
| Power current | 26.5A | Floor heating maxoutlet temp | 50ºC |
| Water temp | 60ºC | Exhaust pressure | ≤2.8MPa |
| Rated heating water capacity | 400L/h | Inhale pressure | ≤0.7MPa |
| Noise | 63dB(A) | Heating exchanger pressure | ≥3.8MPa |
| Quality | 230kg | Electric shock proof grade | I |
| Refrigerant | R410/R407C/R134A | Product dimension | 125*45*180cm |
| Domestic water | 120L | AC conditioner water | 60L |
