Pump Heater For Heating DC Inverter Water To Air Heat Pump Manufacturers Pompa Ciepla with WiFi Warmepumpe

Pump Heater For Heating DC Inverter Water To Air Heat Pump Manufacturers Pompa Ciepla with WiFi Warmepumpe offered by China manufacturer Heat pump,air to water,water to water heat pump-Guangzhou Mango Energy Technology Co.,Ltd. Buy Pump Heater For Heating DC Inverter Water To Air Heat Pump Manufacturers Pompa Ciepla with WiFi Warmepumpe directly with low price and high quality.
Availability:
Quantity:
  • MGSDC-060IC
  • Mango
  • 84186177454
  • Mango Energy
  • ERP A+++,CE, ISO9001, CCC, CB, UL, RoHS, SASO, CSA
  • Ply wood
  • China
  • 1010X435X890(Pakage,MM)
  • Household Bathroom Apartment Hotel vila ect. Heating Hot Water and Cooling
Mango energy Heat Pump Monoblock 20kw Air to Water Heat Pump DC Inverter
Air to Water Heat Pump best selling
Product description
Name:A+++ DC inverter air source heat pump
Function:Hot Water/Heating/Cooling
Package:Wooden package


DC Inverter heat pump Advantages:
1.R32 Refrigerant pipe connection for best system stability even in tough weather.
2.E-heater, diverter valve,water pump,and expansion tank can be included
3.A+++ Energy Rating Level,with CE,TUV test report.
4.Low noise sound power level as low as 52dB(A)
5.Work down to -30 degree C
6. WIFI solution available,Smart controller.
7.Function: Heating +Cooling+ Hot water
8.Max hot water temp 55-60 degree.
Specification
Model

MGSDC-030IIC
MGSDC-050IIC
MGSDC-060IIC
MGSDC-080IIC
Power Supply
V/Ph/Hz
220-240V~/50Hz/1ph, 380-415V/50Hz/3ph
Refrigerant Type

R32
[Space Heating] Ambient Temp. (DB/WB): 7°C/6°C, Water Temp. (Inlet/Outlet): 30°C/35°C
Max Heating Capacity
kW
2.32-9.65
3.53-15.76
4.81-18.85
6.36-25.14
Power Input
kW
0.38-2.10
0.58-3.49
0.81-4.31
1.08-5.81
COP

6.06-4.59
6.01-4.51
5.89-4.37
5.87-4.33
[Space Heating] Ambient Temp. (DB/WB): 7°C/6°C, Water Temp. (Inlet/Outlet): 50°C/55°C
Max Heating Capacity
kW
1.81-7.83
2.38-10.86
2.82-14.12
3.41-17.69
Power Input
kW
0.43-3.05
0.58-4.31
0.64-5.34
0.89-7.04
COP

4.15-2.56
4.11-2.52
4.37-2.64
4.32-2.51
[Space Cooling] Ambient Temp. (DB/WB): 35°C / -, Water Temp. (Inlet/Outlet): 12°C/7°C.
Max Cooling Capacity
kW
1.43-7.80
2.06-11.40
2.63-14.50
3.31-20.52
Power Input
kW
0.32-2.92
0.46-4.3
0.59-5.53
0.76-7.86
COP

4.45-2.68
4.43-2.65
4.41-2.62
4.32-2.61
[Hot Water] Ambient Temp. (DB/WB): 20°C/15°C, Water Temp. from 15°C to 55°C.
Max Heating Capacity
kW
10.5
16
19.5
24.8
Power Input
kW
2.18
3.36
4.04
5.23
COP

4.82
4.76
4.83
4.74
ErP Level (35°C)

A+++
ErP Level (55°C)

A++
Max. Power Input
kW
3.3+3/3.5+3
6+3/6.5+3
6+3/6.5+3
7.7+3/8.0+3
Max. Running Current
A
15+13.6/15.9x3+3
9.1+13.6/9.85x3+13.6
9.1+13.6/9.85x3+13.6
35+13.6/12.12x3+13.6
Compressor Brand

Panasonic
Rated Water Flow
m³/h
≥1.6
≥2.1
≥2.7
≥3.4
Water Pressure Drop
kPa
30
38
38
45
Sound Pressure Level at 1m
dB(A)
43~54
43~55
44~55
45~58
Operation Range
°C
-30~43
Features
A.Top SCOP
Panasonic/Toshiba/Sanyo Inverter Rotary compressor and ECO R32/R410 refrigerant for max heat capacity and less
refrigerant, large volume of latent heat from the air via evaporator in coldest season.
B.Ultra frequency conversion technology
Based on the principle of proportional relationship between motor speed and input frequency of working power supply: n = 60f(1-s)/p and changing motor speed by changing working power frequency of the motor, it adopts AC-DC-AC power conversion technology, relying on our powerful control system with PWM generation ability, integrate V/F, vector control (VC) and direct torque control (DTC) to achieve control method of variable frequency PID calculus, mainly drive variable frequency by way of PWM synthesis drive, fully integrate power, electronics, microcomputer control and other technologies.
C.Advanced Carel Operate System, ultra intelligent
Especially superior heat dissipation circuit board design, longer service, over 3 time of other brand's, simple click and fully
play the characteristics of DC inverter frequency conversion system to achieve overlocking performance.
D.Multi-speed mute fan motor
ROHS fan blades, ultra-low noise, durable & reliable, constant max air flow to satisfy heat supply.
E.Soft-start and soft-shutdown
Protecting both electrical system and all key parts, such a EEV, SANHUA 4-way valve, LG AC contactor & other World famous brand components ensure heat pump device 2-3 time longer service by
1) making output torque of the motor meeting the requirements of mechanical system for starting torque, ensuring smooth acceleration & smooth transition, and avoiding destructive torque impact;
2) achieving both starting current meeting the requirements of motor's bearing capacity, and the insulation damage or burnout caused when it starts.
3) reducing both voltage sag range and the content of high-order harmonics etc.
F.High-tech shock-absorption all copper construction piping
High-accurate completely automatic silver welding, easy maintenance.
G.High-density protective jacket for minimum heat lost
Aviation class insulation foam with outstanding sound absorption.
H.Classic European outlook forming
Fashion taste, never out of time.
I.Portable compact design
Saving room for installation & operation.
J.Fast heating and cooling speed
Before the indoor temperature reaches the set value, the Panasonic rotary compressor delivers high levels of efficiency, enabling the unit to operate at high frequency so that it can heat water or provide house heating/cooling at a faster speed.
Five Working Functions:
Mode 1:Central Hot Water: Constant Temperature, Sufficient Water Volume, 24-hour Instant Supply
Mode 2:Central Cooling: Water Cooled Air Conditioning, Soft Air Supply, Comfortable for Human Body.
Mode 3: Whole House Heating: Water Cycled Floor Heating,Well-distributed Heat Dissipation, Healthy & Energy Saving.
Mode 4: HotWater + House Cooling: Meet the Requirements of Both Central Hot Water and Air Conditioning.
Mode 5: Hot Water + House Heating: Meet the Requirements of Both Central Hot Water and Room Heating.
Wifi smart controller
1.Mango dc inverter heat pump with intelligent CAREL controller with RS485 is adopted to realize the linkage control between the heat pump unit and the terminal application end.
2.With the Cascade function, multiple heat pumps can be controlled at once for greater all day operating efficiency.
3.With WIFI APP enables users to operate their units through a smart phone wherever and whenever they are.

Key part
With A+++ (European) EU Energy Efficiency Label:
Installation reference
For traditional or new radiators space heating
Mangos' factory
Praise from customers:

About after sale service and warranty: 3 years for warranty,if there is any problems with the heat pump without human factor ,we will provide you free heat pump parts or accessories,we will pay for the air freight.and will provide long-term technical guidance,you can contact us anytime, we have after sale department ,we'll work things out for you.
FAQ
Q1> What does mango energy company do ?
A1: Mango energy is professional manufacturer of ON/OFF heat pump , DC inverter heat pump, air source heat pump,water to water heat pump , swimming pool heat pump,high temperature heat pump so on all kind of heat pump.

Q2> What is the daily production of Mango energy company ?
A2: Mango energy one day produce heat pump water heater around 150~255 PCS / day.

Q3> What is Mango heat pump certification ?
A3 : Mango energy have : SGS, CE,CB, IEC60335-2-40, EN14511 certificate from TUV Lab,, got ISO9001. ISO18001, ISO14001 and CCCcertificate. Get Class A+, A as ErP EN14825 test report .

Q4> What Mango energy do for their agent / distributor /OEM ?
A4 : Mango energy offer sales training , heat pump & solar air conditioner product training,
After sales service training , maintenance machine training , big air chiller ,or heating
Project design case training , inside parts exchange training and test training.

Q5> What Mango energy offer to their business partner ?
A5: Mango energy offer 1%~2% free spare parts according to order quantity .
Offer whole this district market exclusive sales right .
Offer rebate as this district agent sales amount within one year .
Offer best competitive price & repair parts .
Offer 24 hours online service .

Q6> where is Mango energy heat pump using ?
A6: Because Air source heat pump save energy around 70% , ( EVI heat pump and central cooling & heating heat pump ) is Widely used in home heating, hotels hot water & heating , restaurants, hospitals,schools,bath center, residential central heating and hot water plants, etc.
