Working at -35 Degree Europe Market Ground Source Heat Pump/ Geothermal Source Heat Pump

Quantity:
  • MG-10SFXRS
  • 10.4kw
  • Mango
  • Plywood
  • 710*520*1000
  • China
  • 8415812000
Water/Geothermal source heat pump (Heating mode, Monoblock type)
Model MG-03SFXRS MG-03SFXRS/380 MG-05SFXRS MG-06SFXRS MG-10SFXRS MG-12SFXRS MG-15SFXRS MG-20SFXRS MG-25SFXRS
Specifications Heating input power KW 2.13 2.39 4.25 5.08 8.5 10.16 11.4 15.1 20.2
Heating capacity KW 10.4 11.6 20.8 24.7 41.6 49.4 55.4 73.1 97.2
COP 4.88 4.85 4.89 4.86 4.89 4.86 4.86 4.84 4.81
Rated current A 13 6 8.8 11.1 17.6 20.7 25.9 36.1 41.4
Max outlet water temp ºC 60 60 60 60 60 60 60 60 60
Rated outlet water temp ºC 55 55 55 55 55 55 55 55 55
Hot water capacity L/H 224 249 447 531 894 1062 1191 1572 2090
Water flow of load side L/h 2100 2100 3200 3800 4800 6200 7300 12400 19800
water flow of source side L/h 1800 2010 3650 4300 7401 8774 9838 12969 17217
Water pressure drop Kpa ≥70 ≥70 ≥70 ≥70 ≥80 ≥80 ≥80 ≥80 ≥80
pipe size mm 25 25 25 25 32 32 32 50 65
noise db 50 50 50 50 50 55 55 55 55
net weight kg 88 88 120 130 280 300 350 540 580
gross weight kg 92 92 130 140 295 315 370 570 620
Level of protection IPX4 IPX4 IPX4 IPX4 IPX4 IPX4 IPX4 IPX4 IPX4
Electric shock proof grade I I I I I I I I I
Standard components cabinet Galvanized sheet/ Spray coating / gray color
dimension mm 710*520*1000 710*520*1000 710*520*1000 710*520*1000 1280*830*800 1280*830*800 1320*840*1130 1750*1120*1160 2000*1120*1160
packing dimension mm 760*570*1130 760*570*1130 760*570*1130 760*570*1130 1330*880*930 1330*880*930 1410*940*1290 1850*1225*1340 2100*1225*1340
Refrigerant R407C/2.4kg*1 R407C/2.4kg*1 R407C/3.3kg*1 R407C/3.6kg*1 R407C/3.3kg*2 R407C/3.6kg*2 R407C/5kg*2 R407C/7kg*2 R407C/9kg*2
Power supply 220V~240V/50Hz/1ph 380V~415V/50Hz/3ph
Power supply L wire line Mm2 2.5 2.5 4 6 6 6 10 10 16
Power supply N wire line Mm2 1.5 2.5 2.5 2.5 2.5 4 4 6
noise db 50 50 50 50 50 55 55 55 55
compressor model ZW30KAE ZW34KAE ZW61KAE ZR72KCE ZR61KCE ZW72KAE ZR81KCE ZW108KAE VR144KSE
compressor Copeland 1pc Copeland 1pc Copeland 2pcs
load side HE Double-pipe heat exchanger shell and tube heat exchanger
source side HE plate heat exchanger
Thermal expansion valve Emerson 3Ton Emerson 3Ton Emerson 5Ton Emerson 6Ton Emerson 5Ton*2 Emerson 6Ton*2 Emerson 7.5Ton*2 Emerson 10Ton*2 Emerson 12Ton*2
AC contactor and thermal relay
Controller multiple function controller
Protection function Tempreature protection, time protection, water flow protection, antifreeze protection, current protection
Water pressure switch 0.015Mpa :OFF, 0.03Mpa: ON
High pressure switch 3.0/3.4MPa
Low pressure switch 0.15/0.32MPa
Package Plywood case
working mode heating mode

Remarks:
Exclude: inside water pump, water tank
Changeable items: 1.compressor brand, 2.gas type, 3.cabinet material, 4.power supply according to user's real condition....., price will be changed accordingly.
Working range:source side water inlet temp: 0ºC-40ºC
Rated workong condition:Source side inlet/outlet water temp: 15ºC/10ºC,load side inlet/outlet water temp:50ºC/55ºC;

Working at -35 Degree Europe Market Ground Source Heat Pump/ Geothermal Source Heat Pump

Working at -35 Degree Europe Market Ground Source Heat Pump/ Geothermal Source Heat Pump
